3 Axle Timber Semi Trailer
Timber trailer is mainly used in forest log transport, long tube transport, etc., to adapt to long-distance road transport and bad road transport.adaptable, trailer design is reasonable, load capacity and other advantages, by the wood producers of ages.
Description
BST VEHICLE build timber trailer from 10 to 60 tons payload . Whether flexible cargo area, sliding axles, drive
solutions, different brake systems which also can be combined together or safety features.
The vehicles can be used in forestry, long-distance haulage and off-road applications, whereby they are
equally suitable for long timber as well as for short timber and lumber.
solutions, different brake systems which also can be combined together or safety features.
The vehicles can be used in forestry, long-distance haulage and off-road applications, whereby they are
equally suitable for long timber as well as for short timber and lumber.
| Dimension | 12,500*2,500*3,900 mm |
| Load capacity | 60 tons |
| Axles | 3 * 20 tons axles |
| Tire | 11.00R20 radial tires |
| Suspension | mechanical suspension |
| Landing gear | JOST C200 |
| Kingpin | 2 inch or 3.5 inch |
| Brake system | WABCO or Haldex system |
| Electric | 12V or 24V |
| Plug | number: 12pcs , height:1,000mm |
| Mud guard | anti- spray type |
| Bumper | Heavy duty push bumper |
| Painting | blasted , primed and painted with Enamel |
