Gooseneck Container Trailer
Load weight:40ton
2 Axle Gooseneck Container Trailer (For 20 Feet)
3 Axle Gooseneck Container Trailer (For 20-30-40-45 Feet)
4 Axle Gooseneck Container Trailer(For 20-30-40-45 Feet)
Supply Ability:
200unit/Sets per Month
2 Axle Gooseneck Container Trailer (For 20 Feet)
3 Axle Gooseneck Container Trailer (For 20-30-40-45 Feet)
4 Axle Gooseneck Container Trailer(For 20-30-40-45 Feet)
Supply Ability:
200unit/Sets per Month
Description
| Product type | Gooseneck Container Trailer |
| Outside dimension | Length:12400mm,width :2500mm,height:1575mm size can be choose freely |
| Tare weight | About 6.2T |
| Loading capacity | 30T-45T |
| Axle | 13T/16T,FUWA/BPW Brand |
| ABS system | Optional |
| Suspension | Mechanical suspension (Germany type or America type) or Air suspension (china brand or BPW brand ) |
| Spring leaf | 90(W)mm*13(Thickness)mm*10Layer,optional |
| Tires | 12.R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be optional |
| Rim | 9.00-22.5/8.00-20/8.5-20 China brand |
| King pin | JOST 2.00 or 3.5 inch |
| ABS | Optional |
| Valve | WABCO valve |
| Support legs | JOST brand |
| The material of main beam | The height of the beam is 500mm ,upper plate is 14mm ,down plate is 16mm,middle plate is 8mm .material is Q345B steel |
| Twist locks | Four ,eight or twelve pieces |
| Floor plate | 3mm diamond steel plate |
| Support leg | JOST brand |
| Brake Chamber | WABCO BE 6 RELAY VALVE ;T30/30+T30 Spring brake chamber (TKL brand) ; Two pieces of 45L air tanks or China brand |
| Electrical system | 24v,7 wire harness |
| Light | LED light (special for export market ) |
| Tool box | One piece 1mx0.5mx0.5m (size can be choose freely ) |
| Painting | Compete Chassis sand blasting to clean rust ,1 coat of anti-corrosive prime ,2coats of final paint |
BST offers high quality skeleton gooseneck trailers and competitive prices. if you intereted our Gooseneck Container Trailer.please contact us.
